General purpose GREEN ESD Mat
A) Product Name
ESD Green Rubber Mat
B) Raw Material
NBR + Synthetic Rubber
C) Purpose
To prevent equipment damage resulting from the triboelectric voltage of the static dissipative
D) Scope
Ideal for use in Workstations, Electronic Manufacturing, Pharmaceutical Plants, Cleanrooms, Fiber Optics, Electronic Assembly, Electronic Warehousing, Circuit Assembly, Aerospace, CMOS chips, microprocessor, semiconductors, dish drivers, composites, LCD screen products, circuit product lines, hospitals and Pharmaceutical industries, precision instrument etc
E) Characteristics
1 ) The anti-static mat is made up of two layers, the top layer ( hard ) is static dissipative, and the bottom layer ( soft ) is conductive.
2) Features:-
The anti-static properties of the mat are according to the relative requirements of SJ/T 10694-1996.
The surface resistance of the static dissipative layer ( 1.0 x 10e6 ~ 10e9 Ω )
The surface resistance of the conductive layer ( Below 1.0 x 10e6 Ω )
Volume resistance ( 1.0 x 10e6 ~ 10e9 Ω )
The triboelectric surface voltage of the static dissipative material < 200 V
The time of static discharging below 100V should be less than 1 second.
3) Model No. : ESD1GRN0.61X10S , ESD1GRN0.61X10D , ESD2GRN1X10S , ESD2GRN1X10D , ESD3GRN1.2X10S , ESD3GRN1.2X10D ,
4) Compliant to GB/T14437-97.
5) RoHS compliant.
6) Top Layer Material: Green ( NBR Rubber ),
Bottom Layer Material: Black ( Synthetic Rubber ).
7) Surface Resistivity:
a) Top ( 1.0 × 10 ⁷ ~ 1.0 × 10⁹ Ohms )
b) Bottom ( 1.0 × 10 ²~ 1.0 × 10 ⁶Ohms )
8) Hardness ( IRHD, Micro Hardness Tester Wallace )
a) Top Green Layer: 70 ± 5° ( Shore A )
b) Bottom Black layer: 50 ± 5° ( Shore A )
9) Overall Thickness: Minimum 2.00 mm
10) Surface Finishing: Matt ( Dull ) & Glossy ( Shining )
F) Specifications
1) Model No. : ESD1GRN0.61X10S, ~2mm ( Thickness ) x 610mm ( 2ft ) ( Width ) x 10,000mm ( 10m ) ( length ) / roll, weight around 18.5kgs / roll, Shining / Glossy Green, SGS Test Report: CRSSA/190411621-CA09968
2) Model No. : ESD1GRN0.61X10D, ~2mm ( Thickness ) x 610mm ( 2ft ) ( Width ) x 10,000mm ( 10m ) ( length ) / roll, weight around 18.5kgs / roll, Dull / Matt Green, SGS Test Report: CRSSA/190411618-CA09965
3) Model No. : ESD2GRN1X10S, ~2mm ( Thickness ) x 1,000mm ( 1m ) ( Width ) x 10,000mm ( 10m ) ( length ) / roll, weight around 30kgs / roll, Shining / Glossy Green, SGS Test Report: CRSSA/190411622-CA09969
4) Model No. : ESD2GRN1X10D, ~2mm ( Thickness ) x 1,000mm ( 1m ) ( Width ) x 10,000mm ( 10m ) ( length ) / roll, weight around 30kgs / roll, Dull / Matt Green, SGS Test Report: CRSSA/190411619-CA09966
5) Model No. : ESD3GRN1.2X10S, ~2mm ( Thickness ) x 1,200mm ( 4ft ) ( Width ) x 10,000mm ( 10m ) ( length ) / roll, weight around 36kgs / roll, Shining / Glossy Green, SGS Test Report: CRSSA/190411623-CA09970
6) Model No. : ESD3GRN1.2X10D, ~2mm ( Thickness ) x 1,200mm ( 4ft ) ( Width ) x 10,000mm ( 10m ) ( length ) / roll, weight around 36kgs / roll, Dull / Matt Green, SGS Test Report: CRSSA/190411620-CA09967
MATT / DULL
SHINING / GLOSSY
Disclaimer :
* Note : Users need to evaluate suitability for their industries use ( applications ) before placing order from us .
* Note : Users need to evaluate suitability for their industries use ( applications ) before placing order from us .
